Technical Specifications
| X, Y, Z Axis Travel |
850 x 600 x 610 mm |
| Table Size |
1.050 x 600 mm |
| Spindle Type |
BT-40 / Direct Drive |
| Spindle RPM |
12.000 rpm/min |
| Spindle Motor Power |
15,0 kW |
| X, Y, Z Axis Rapid Travel |
48/48/36 m/min |
| X, Y, Z Axis Cutting Speed Rate |
20 m/min
|
| Tool Change Type |
Arm Type - 24 Tool Capacity |
| Weight |
5.700 kg |
Accessories / Hardware
MITSUBISHI M80 (2A) CNC Control Unit
15.4’ LCD/TFT Colour Touch Screen
Linear Guides with High Precision and Strength in X, Y, Z Axes
C-3 Quality Pre-Tensioned Ball Screws
‘MEHANITE’ Strength and Precision Casting Body Structure
Fully Enclosed Cabin & In-Cab Wash System
Spindle Oil Cooling System & Spindle Continuous Air Curtain System
Pressurised Cutting Fluid Spraying System from Spindle End
Pressurised Air and Water Spray System around the Spindle
In-Cab LED Lighting System x 2 Pieces & LED Work Lamp
Programmable Central Lubrication System from Automatic (Alarm) Unit
Stainless Telescopic Slideway Protector System in X, Y, Z Axes
Screw Type Chip Disposal Screw & Chip Trolley
Spare Air Tank For Tool Changer
Automatic End of Programme Worktop Shutdown Function
Handwheel (MPG)
Electric Cabinet Heat Equalisation System
3 Colour Alarm Lamp
Air & Water Gun
Bench Operation and Maintenance Books
MITSUBISHI Programming and Operation Books
Electrical and Safety Equipment in accordance with CE Norms
1 Year Mechanical Bench Warranty
2 Year Control Unit Warranty
