Technical Specifications
| Chuck Size |
12" |
| Maximum Turning Capacity |
Ø 600 mm |
| Maximum Turning Diameter |
Ø 450 mm |
| Turning Length |
990 mm |
| Spindle RPM |
3.200 dv./dk. |
| Spindle Motor Power |
22,0 kW |
| X, Z Axis Movement |
245 x 1.110 mm |
| Turret Type |
Hydraulic Turret - 12 Stations |
| Weight |
6.000 kg |
Accessories / Hardware
FANUC 0i-TF Plus CNC Control Unit
10.4’ LCD/TFT Colour Screen
Ethernet Connection Unit
RS-232 Connection Unit
CF Card Reading Slot, USB Reading Slot
C-3 Quality Pre-Tensioned Ball Screws
X, Z Axes Hydrostatic Friction Box Slideway
‘MEEHANITE’ Precision Casting Body Structure with Strength and Monoblock Inclined Bank
Hydraulic 12 Station Turret
RENISHAW Fully Automatic Tool Measuring Arm
12’ (Ø350 mm) 3 Legged Hydraulic Chuck
Safe Non-Scatter Tempered Cabin Glass
Fully Enclosed Cabin,
Cabin Lighting System
3 Colour Alarm Lamp
Programmable Central Lubrication System from Automatic (Alarm) Unit
Stainless Telescopic Slideway Protector System in X, Z Axes
Belt Type Chip Disposal Conveyor & Chip Trolley
Automatic End of Programme Worktop Shutdown Function
Handwheel (Manual Pulse Generator)
Electric Cabinet Heat Equalisation System
Soft Foot Set (5 Sets)
Hard Foot Set (1 Set)
Rotary Tailstock Set (1 Set)
Morse Conical Set (1 Set)
Standard Tool Holder Set (1 Set)
Suits & Suit Bag
Bench Use and Maintenance Books
FANUC Programming and Operating Books (USB)
Electrical and Safety Equipment in accordance with CE Norms
1 Year Mechanical Bench Warranty Against Production Defects
2 Year International FANUC Control Unit Warranty
